1. Ultra-high precision: It is designed with precision screw and guide rail plus servo motor to drive the metering mechanism. The injection position accuracy is within 0.01mm. Electric servo plunger type metering injection, high mixing material tube servo motor drive, follow-up Speed ratio dynamic mixing.
2. High performance: Servo motor and precision ball screw drive double-slide die-moving, precision linear slide guide to achieve high displacement and positioning accuracy in X and Y directions,
3. High efficiency: the mold clamping is more accurate and does not eccentrically wear the mold guide column and guide sleeve, which can achieve the precision of the CNC processing machine, avoid the instability of the traditional oil cylinder slide plate, and save the positioning time and adjustment.
4. High stability: self-developed PLC electronic control system, user-friendly operation man-machine interface; with automatic pump lubrication system, free of daily maintenance. The action flow can be additionally changed according to customer requirements. The one-piece frame is stress-removed, and the high-grade ductile iron one-piece template is stable and has a long service life.
